| Camera | |
| Image Sensor | 1/3" Sensor |
| Min. Illumination | 0.01 lux @F1.2, AGC ON, 0 lux with IR |
| Shutter Time | 1/3s ~ 1/100,000s |
| Lens | 4mm Angle of view: 79° |
| Lens Mount | M12 |
| Day & Night | Auto switch |
| Digital Noise Reduction | 3D DNR |
| Wide Dynamic Range | Digital WDR |
| Ange Adjustment | Pan: 0° - 355°, Tilt: 0° - 80° |
| Compression Standard | |
| Video Compression | H.264 / MJPEG |
| H.264 Type | BaseLine Profile / Main Profile |
| Bit Rate | 32 Kbps ~ 8Mbps |
| Dual Stream | Yes |
| Image | |
| Max. Image Resolution | 1920 x 1080 |
| Frame Rate |
60Hz: 30fps (1920 ×1080), 30fps (1280×960),30fps (1280×720)
50Hz: 25fps (1920 ×1080),25fps (1280×960),25fps (1280×720)
|
| Image Settings |
Rotate mode, Saturation, Brightness, Contrast adjustable by client software or web browser
|
| BLC | Yes, zone optional |
| ROI | Support |
| Network | |
| Network Storage |
Local storage: Built-in Micro SD/SDHC/SDXC card slot, up to 64 GB. NAS (Support NFS,SMB/CIFS)
|
| Alarm Trigger |
Line Crossing, Intrusion Detection, Motion detection, Dynamic a
nalysis,Tampering alarm, Network disconnect, IP address conflict,
Storage exception
|
| Protocols |
TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,DDNS,RTP,RTSP,RTCP,
PPPoE,NTP,UPnP,SMTP,SNMP,IGMP,802.1X,QoS,IPv6,Bonjour
|
| General |
One-key reset, Flash-prevention, dual stream, heartbeat, mirror
, passwordprotection, privacy mask, watermark, IP address filtering, Anonymous access
|
| Standard | ONVIF, PSIA, CGI, ISAPI |
| Interface | |
| Communication Interface | 1 RJ45 10M/100M Ethernet interface |
| General | |
| Operating Conditions |
14°F ~ 104 °F(-10 °C ~ 40°C ) humidity 95% or less (non-condensing)
|
| Power Supply | 12 VDC ± 10% , PoE (802.3af) |
| Power Consumption | Max. 4.5W |
| Dimension | Φ3.7”× 4.8”(Φ93.9×121.6mm) |
| Weight | 0.4lbs(200g) |
