| Camera | |
| Image Sensor | 1/3" Progressive Scan CMOS |
| Min. Illumination | 0.01Lux @(F1.2,AGC ON), 0.014 Lux @(F1.4,AGC ON), 0 Lux with IR |
| Shutter Speed | 1/3 s to 1/10,000 s |
| Slow Shutter | Support |
| Lens | 2.8-12mm @ Fmm |
| Lens Mount | M12 |
| Day & Night | IR cut filter with auto switch |
| DNR | 3D DNR |
| Wide Dynamic Range | DWDR |
| Compression Standard | |
| Video Compression | H.264 /MJPEG /H.264 Zip+ |
| H.264 Type | Main Profile |
| Video Bit Rate | 256 Kbps ~ 16 Mbps |
| Audio Compression | G.711/G.722.1/G.726/MP2L2 |
| Audio Bit Rate | 64Kbps(G.711) / 16Kbps(G.722.1) / 16Kbps(G.726) / 32-128Kbps(MP2L2) |
| Image | |
| Max. Resolution | 2560×1920 |
| Frame Rate | 60Hz: 20fps (2560×1920), 30fps (2048x1536), 30fps(1920×1080), 30fps(1280×720) 50Hz: 20fps (2560×1920), 25fps (2048x1536), 25fps(1920×1080), 25fps(1280×720) |
| Sub Stream | 60Hz: 30fps (352×240, 640x480) 50Hz: 25fps (352×288, 640x480) |
| Others | Saturation, Brightness, Contrast adjustable by client software or web browser, Mirror, BLC, ROI, Dual Stream, Anti-Flicker, Privacy Mask |
| Network | |
| Network Storage | NAS (Support NFS,SMB/CIFS), ANR |
| Alarm Trigger | Motion Detection, Tampering Alarm, Intrusion Detection, Line Crossing Detection, HDD Full, HDD Error, Network Disconnected, IP Address Conflicted |
| Protocols | TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour |
| General | Password Protection, IP Address Filtering, Anonymous Access, Watermark |
| Standard | ONVIF (PROFILE S, PROFILE G), PSIA, CGI, ISAPI |
| Interface | |
| Communication Interface | 1 RJ45 10M/100M Ethernet port |
| On-board Storage | Built-in Micro SD/ SDHC/SDXC slot, up to 128 GB |
| Reset | Yes |
| Alarm Interface | 1x alarm I/O |
| Audio Interface | 1x audio I/O |
| General | |
| Working Temperature /Humidity |
-22 °F ~ 140°F (-30 °C ~ 60 °C) Humidity 95% or less (non-condensing) |
| Power Supply | DC 12V ± 10%, PoE (802.3af) |
| Power Consumption | Max. 5.5W (Max 7.5 W with IR cut filter on) |
| IR Range | Approx. 100ft(30 meters) |
| Weather Proof Ratings | IP66 |
| Dimensions | 3.7" × 4.1" × 10.2" (95 × 105 × 258.6mm) |
| Weight | 2.7lbs (1200 g) |
