Camera | |
Image Sensor | 1/3” sensor |
Min. Illumination | 0.07 lux @F1.2, AGC on 0 lux with IR |
Shutter Speed | 1/25s ~ 1/100,000s |
Lens | 4.0 mm @F2.0, Angle of view: 79° |
Lens Mount | M12 |
Day & Night | IR cut filter with auto switch |
Digital Noise Reduction | 3D DNR |
Compression Standard | |
Video Compression | H.264 / MJPEG |
Bit Rate | 32 Kbps ~ 8 Mbps |
Dual Stream | Yes |
Image | |
Max. Resolution | 1920 × 1080 |
Frame Rate | 60 Hz: 30fps (1920 ×1080), 30fps (1280×960) , 30fps (1280×720) 50 Hz: 25fps (1920 ×1080), 25fps (1280 ×960), 25fps (1280×720) |
Image Settings | Rotate mode, Saturation, Brightness, Contrast adjustable by ciel nt software or web browser |
BLC | Yes,zone optional |
ROI | Yes, up to 4 configurable areas |
Network | |
Network Storage | NAS |
Alarm Trigger | Motion detection, Dynamic analysis, Tampering alarm |
Protocols |
TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,DDNS,RTP,RTSP,RTCP,PPPoE,NTP, UPnP,SMTP,SNMP,IGMP,802.1X,QoS,IPv6,Bonjour |
System compatibility | ONVIF, PSIA, CGI, ISAPI |
General functionalities | User Authentication, Watermark |
Interface | |
Communication Interface | 1 RJ45 10 M / 100 M Ethernet interface |
Reset Button | Yes |
General | |
Working Temperature /Humidity |
-22 °F ~ 140 °F(-30 °C ~ 60 °C ) Humidity 95% or less (non-condensing) |
Power Supply | DC12V±10% / PoE(802.3af) |
Power Consumption | Max. 7W |
Weather proof rating | IP66 |
IR Range | Up to 100ft(30m) |
Dimension | 2.4” × 3.0” × 5.5”(60.5 x 76.9 x 139.2mm) |
Weight | 1.1lbs(500g) |
