| Camera | |
| Image Sensor | 1/3" sensor |
| Min. Illumination | 0.07Lux @ (F1.2, AGC ON), 0 Lux with IR 0.19 @ (F2.0, AGC ON), 0 Lux with IR |
| Shutter Time | 1/3s ~ 1/100,000s |
| Lens | 2.8mm @F2.0 Angle of View: 98.5° |
| Lens Mount | M12 |
| Angle Adjustment | Pan: 0° - 355°, Tilt: 0° - 75°, Rotation: 0° - 355° |
| Digital Noise Reduction | 3D DNR |
| Wide Dynamic Range | Digital WDR |
| Day & Night | ICR |
| Compression Standard | |
| Video Compression | H.264 / MJPEG |
| H.264 Codec Profile | Main profile |
| Bit Rate | 32 Kbps ~ 12 Mbps |
| Dual Stream | Yes |
| Image | |
| Max. Image Resolution | 2048 x 1536 |
| Frame Rate | 60 Hz: 20fps (2048 x 1536), 30fps (1923 x 1080), 30fps (1280 x 720) 50Hz: 20fps (2048 x 1536), 25fps (1920 x 1080), 25fps (1280 x 720) |
| Image Settings | Rotate mode, Saturation, Brightness, Contrast adjustable by client software or web browser |
| BLC | Yes, zone optional |
| ROI | Support |
| Network | |
| Network Storage | Local storage: Built-in Micro SD/SDHC/SDXC card slot, up to 64GB. NAS (support NFS, SMB/CIFS) |
| Alarm Trigger | Intrusion detection, Line crossing detection, Motion detection, Dynamic Analysis, Tampering alarm, Network Disconnect, IP address conflict, Storage full, Storage error |
| Protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour |
| System Compatibility | ONVIF, PSIA, CGI, ISAPI |
| Security | User Authentication, Watermark |
| Interface | |
| Communication Interface | 1 RJ45 10M / 100M ethernet port |
| General | |
| Operating Conditions | -22° F ~ 140° F(-30° C ~ 60° C) Humidity 95% or less (non-condensing) |
| Power Supply | 12 VDC 10%, PoE (802.3af) |
| Power Consumption | Max. 5W |
| Impact Protection | IEC60068-275Eh, 50J; EN50102, up to IK10 |
| Ingress Protection | IP66 |
| IR Range | Approx 100 ft (About 30m) |
| Dimensions | 4.4" x 3.2" (111.0 x 82.4mm) |
| Weight | 1.1lb (500g) |
