| Camera | |
| Image Sensor | 1/3" sensor |
| Min. Illumination | 0.14 lux@F2.0, AGC on 0 lux with IR |
| Shutter time | 1/25s ~ 1/100,000s |
| Lens | 2.8mm@F2.0 2048 × 1536: angle of view: 86° 1920 × 1080: angle of view: 98.5° |
| Lens Mount | M12 |
| Angle adjustment | Horizontal: 0° ~ 360°, vertical: 0° ~ 75°, rotation: 0° ~ 360° |
| Digital noise reduction | 3D DNR |
| Wide dynamic range | Digital WDR |
| Day& Night | ICR |
| Compression Standard | |
| Video Compression | H.264 /MJPEG |
| Bit Rate | 32 Kbps ~ 16 Mbps |
| Dual stream | Yes |
| Image | |
| Max. Image Resolution | 2048x1536 |
| Frame Rate | 60Hz: 20fps (2048 x 1536), 30fps (1920 x1080), 30fps (1280 x 720) 50Hz: 20fps (2048 x 1536), 25fps (1920 x 1080), 25fps (1280 x 720) |
| Image Settings | Saturation, brightness, contrast adjustable through client software or web browser |
| Network | |
| Network Storage | NAS (iSCSI optional) |
| Alarm Trigger | Motion detection, tampering alarm, network disconnect , IP address conflict, storage exception |
| Protocols | TCP/IP, HTTP, DHCP, DNS, DDNS, RTP, RTSP, PPPoE, SMTP, NTP, SNMP, HTTPS, FTP, 802.1x, Qos (SIP, SRTP, IPv6 optional) |
| System Compatibility | ONVIF, PSIA, CGI |
| General functionalities | Flickerless, heartbeat, mirror, user authentication, video mask, watermark,reset |
| Interface | |
| Communication Interface | 1 RJ45 10M / 100M ethernet interface |
| General | |
| Operating Conditions | -13°F ~ 140°F(-25°C ~ 60°C) Humidity 95% or less (non-condensing) |
| Power Supply | 12 VDC ± 10%, PoE (802.3af) |
| Power Consumption | Max. 7W |
| Weather Proof | IP66 |
| IR Range | Up to 100 ft(30m) |
| Dimensions | Φ5.0”x3.8”(127.0 x 97.5 mm) |
| Weight | 1.5lb(670g) |
