| Compression Format | H.264 | ||
| OS | Embedded Linux | ||
| IP Video Input | 64-ch, Max 160Mbps Input | ||
| VGA Output | 1-ch, resolution: 1920×1080P/60Hz,1600×1200/60Hz,1280×1024/60Hz, 1280×720/60Hz, 1024×768/60Hz |
||
| CVBS Output | 1-ch, BNC (1.0 Vp-p, 75 Ω) | ||
| HDMI Output | 1-ch, resolution: 1920 × 1080P /60Hz, 1920 × 1080P /50Hz, 1600 × 1200 /60Hz, 1280 × 1024 /60Hz, 1280 × 720/60Hz, 1024 × 768 /60Hz |
||
| Recording Resolution | 6MP / 3MP / 2MP / 1080P / 720P / VGA / D1 / VGA / DCIF / 2CIF / CIF / QCIF | ||
| Simultaneous Playback | 16-ch | ||
| Playback Resolution | 6MP / 3MP / 2MP / 1080P / 720P / VGA / D1 / VGA / DCIF / 2CIF / CIF / QCIF | ||
| Dual Stream | Main and Sub-Streams | ||
| Audio Input | 1-ch BNC | ||
| Audio Output | 1-ch BNC | ||
| Backup Format | MP4 | ||
| SATA | 8 SATA Interfaces for 8HDDs | ||
| e-SATA | 1 eSATA Interface | ||
| Capacity | Up to 6TB capacity for each disk | ||
| Array type | RAID 0,1,5,10 supported | ||
| Number of array | 4 | ||
| Number of virtual disk | 8 | ||
| Network Interface | 2 RJ45 10M/100M/1000M adaptive Ethernet | ||
| USB Interface | 3 USB 2.0 Interfaces | ||
| Serial Interface | 1 RS-485, 1xRS-232 | ||
| Alarm Input: | 16 | ||
| Alarm Output | 4 | ||
| Mobile App | NVMS7000 for iPhone/iPad/Android | ||
| Power Supply | 100 ~240VAC | ||
| Consumption | ≤ 45 W (without hard disk) | ||
| Working Temperature | -10 °C ~ 55 °C | ||
| Humidity | 10%~90% | ||
| Dimensions | 445 × 470 ×90 mm (17.52" ×18.5"× 3.54") | ||
| Weight | ≤ 8 Kg (17.64 lb) ( without hard disk or DVD-R/W ) | ||
