| Video/Audio input | |
| IP video input | 64-ch |
| Two-way audio input | 1-ch, BNC (2.0 Vp-p, 1kΩ) |
| Incoming bandwidth | 160Mbps |
| Video/Audio output | |
| Recording resolution | 5MP / 3MP / 1080P / UXGA / 720P / VGA / 4CIF / DCIF / 2CIF / CIF / QCIF |
| CVBS output | 1-ch, BNC (1.0 Vp-p, 75 Ω) Resolution: 704 × 576 (PAL); 704 × 480 (NTSC) |
| HDMI output | 1-ch, resolution: 1920 × 1080P /60Hz, 1600 × 1200 /60Hz, 1280 × 1024 /60Hz, 1280 × 720 /60Hz, 1024 × 768 /60Hz |
| VGA output | 1-ch, resolution: 1920 × 1080P /60Hz, 1600 × 1200 /60Hz, 1280 × 1024 /60Hz, 1280 × 720 /60Hz, 1024 × 768 /60Hz |
| Audio output | 2-ch, BNC (Linear, 600Ω) |
| Playback resolution | 5MP / 3MP / 1080P / UXGA / 720P / VGA / 4CIF / DCIF / 2CIF / CIF / QCIF |
| Synchronous playback | 16-ch |
| Hard disk | |
| SATA | Up to 8 SATA interfaces |
| eSATA | 1 eSATA interface |
| Capacity | Up to 6TB capacity for each HDD |
| External interface | |
| Network interface | 2, 10M / 100M / 1000M self-adaptive Ethernet interface |
| Serial interface | RS-232, RS-485, RS-485 keyboard |
| USB interface | 3 × USB 2.0 |
| Alarm in | 16 |
| Alarm out | 4 |
| General | |
| Power supply | 100 ~ 240VAC, 6.3A, 50 ~ 60Hz |
| Consumption | ≤ 40 W |
| Working temperature | -10 ºC ~ +55 ºC(14°F ~ 131°F) |
| Working humidity | 10% ~ 90% |
| Dimensions(W × D × H) | 445 × 470 × 90 mm (17.52" ×18.5"× 3.54") |
| Weight | ≤ 8 kg (17.64 lb) ( without hard disk or DVD-R/W ) |
