| Video/Audio Input | |
| IP Video Input | 16-CH |
| Two-Way audio Input | 1-ch, RCA (2.0 Vp-p, 1kΩ) |
| Network | |
| Incoming Bandwidth | 160Mbps |
| Outgoing Bandwidth | 80Mbps |
| Remote Connection | 128 |
| Video/Audio Output | |
| Recording Resolution | 6MP/3MP/1080P/UXGA/720P/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
| Frame Rate | Main stream: 50 fps (P) / 60 fps (N) Sub-stream: 50 fps (P) / 60 fps (N) |
| HDMI/VGA Output | 1-ch, resolution: 1920 × 1080 /60Hz, 1600 × 1200 /60Hz, 1280 × 1024 /60Hz, 1280 × 720 /60Hz,1024 × 768 /60Hz |
| Audio Output | 1-ch, RCA (Linear, 1kΩ) |
| Decoding | |
| Live View/Playback Resolution | 6MP/3MP/1080P/UXGA/720P/VGA/4CIF/DCIF/2CIF/CIF/QCIF |
| Capability | 16-ch@4CIF, 12-ch@720P, 6-ch@1080P |
| Hard Disk | |
| SATA | 2 SATA interfaces for 2 HDDs |
| Capacity | Up to 6TB for each disk |
| External Interface | |
| Network Interface | 1 RJ-45 10 /100 /1000 Mbps self-adaptive Ethernet interface |
| USB Interface | 1 × USB 2.0 and 1 × USB 3.0 |
| PoE | |
| Interface | 16 independent 100 Mbps PoE network interfaces |
| Max. Power | 200W |
| Supported Standard | AF and AT |
| General | |
| Power Supply | 100~240V AC |
| Consumption | ≤ 15W |
| Working Temperature | +14 ºF~ + 131 ºF(-10 ºC ~ +55 ºC ) |
| Working Humidity | 10% - 90% |
| Casing | 19-inch rack-mounted 1U casing |
| Dimensions (WxDxH) | 445 × 290 × 45mm (17.5 ×11.4 × 1.8 inch) |
| Weight | ≤ 1 kg (2.2 lb) |
