Signal System | NTSC |
Image Sensor | 1/3″ 960H Interline CCD |
Scanning System | 2:1 Interlace |
Horizontal Resolution | 750TV Lines |
Scanning Frequency (H) | 15.734 KHz |
Scanning Frequency (V) | 59.94 Hz |
Total Pixels (H x V) | 1020 x 508 |
Effective Pixels (H x V) | 976 x 494 |
Synchronization | Internal |
Lens | C / CS Mount |
Lens Type | Manual / DC |
S/N | More than 50dB (AGC: Off) |
Gamma | r = 0.45 |
Min. Illumination | 0.05 Lux (Color) / 0.003 Lux (B/W) (30 IRE@F1.4) |
Shutter Speed | 1/60 ~ 1/100,000 sec |
Day & Night | True Day & Night with ICR Mechanism |
Day & Night Function | Auto, Color, B/W |
Video Output Level | 1 Vp-p Composite (75 Ω) |
On-Screen Display (OSD) | Built-in |
BLC | Off, BLC, HLC |
DNR | 2D DNR |
ATR | On / Off (Level Adjustable) |
White Balance | ATW, Push, User1, User2, Anti CR, Manual, Push-lock |
Privacy Masking | 4 Zones |
Mirror | On / Off |
Motion Detection | 4 Zones |
Other Function | Brightness, Contrast, Sharpness, HUE, Gain |
Language Option | English, Japanese, German, French, Russian, Portuguese, Spanish |
Operating Temperature | 14 °F ~ 122 °F (-10 °C ~ 50 °C) |
Storage Temperature | -4 °F ~ 140 °F (-20 °C ~ 60 °C) |
Humidity | Less than 80% RH |
Power Supply | DC Type: DC 12V (±10%), Max. 130mA Dual Type: DC 12V (±10%), Max. 180mA / AC 24V (±10%), Max. 2.9W |
External Control | RS-485 |
Dimension | 2.3 x 2.3 x 2.7 inch (58 x 58 x 69 mm) |
Weight | 0.4 lbs (200 g) |
