Camera | Image Sensor | 3.27 Megapixel, 1/2.8″ SONY Exmor CMOS |
Total Pixel (H x V) | 2144 x 1588 | |
Day & Night | True Day & Night with ICR Mechnism | |
Min. Illumination | 0.1 Lux / F2.0 | |
Shutter Speed | 1/30 ~ 1/10,000 | |
Lens | Focal Lenght | 12x Optical / 10x Digital Zoom (5 ~ 60 mm Lens) |
Lens Type | 12x Optical Zoom Lens | |
Video | Maximum Resolution | H.264 : 1920 x 1080 (16:9) MJPEG : 1280 x 720 (16:9) |
Frame Rate | H.264: 30fps / MJPEG: 30fps | |
Compression | H.264 / MJPEG | |
Streaming | Dual-Stream at different frame rate and bandwidth | |
Digital Slow Shutter | 2x ~ 64x | |
Image Settings | Brightness, Contrast, Saturation, Sharpness, White balance, Exposure control, Text and image overlay, Privacy masking, BLC | |
Audio | Streaming | Two-way, Full Duplex |
Compression | G.711, G726 | |
Input / Output | External Microphone or Line Input / Line Output | |
Network | LAN | Ehternet 10/100 Base-T (RJ-45 Type) |
Security | Multiple user access levels with password protection, HTTPS (SSL) | |
Protocols | IPv4, HTTP, TCP, RTSP, RTP, UDP, IGMP, RTCP, SMTP, FTP, ICMP, DHCP, ARP, DNS, DDNS, HTTPS, UPnP | |
Onvif Compliant | Yes | |
Interface | OS: Windows XP / Vista / 7 Browser: Internet Explorer | |
Intelligent Video | Video Motion Detection | Yes |
Alarm and Event | Alarm Triggers | Intelligent video, external inputs, manual triggers, network fail, reboot |
Alarm Events | JPEG image upload via FTP & Email, notification via E-mail, external output activation | |
General | Processors | CPU: ARM 926EJ-S |
Memory | RAM: 128MB, Flash: 64MB | |
Power | PoE class 4 (IEEE 802.3at Type2) AC 24V 38.5 W (Heater on) |
|
Interface | Analog Composite Output Power (AC 24V) Input Sensor Input x 1 / Alarm Output x 1 Audio Input x 1 / Audio Output x 1 RS485, Status LED |
|
IP Rating | IP66 (Weather Resistant) | |
Operating Temperature | -40 ËšF ~ 122 ËšF (-40 ËšC ~ 50 ËšC) | |
Dimension | Bubble (Φ4.4), Φ6.5 x 13.4 x 10 inch (Bubble (Φ112), Φ166 x 341 x 255 mm) | |
Weight | 7.7 lbs (3500 g) |
