Imaging Device | 1/2.8” Sony 2.1Mp Progressive Scan CMOS |
Video Format | Main Output : 1080p30/25, 720p/30/25 HD-TVI (OSD selectable) |
Secondary Output : CVBS (OSD selectable NTSC/PAL) service video test point | |
Actual/Effective Picture Elements | 2000 (H) x 1121 (V) / 1984 (H) x 1105 (V) |
Maximum Video Output Resolution | 1920 (H) x 1080 (V) / 1080p @ 30/25 |
Sensitivity | .1 lux color, .07 lux B/W (F=1.0) |
Day/Night Type | Digital Day/Night |
Lens Type | CS Type [C-mount with included adapter] DC iris support |
Video Output Connector Type | TVI and CVBS : BNC 75Ω |
Sync. Mode | Internal |
OSD Menu | Multiple functions using 5 button controls on rear of housing; UTC Control |
OSD Languages | English, Spanish, Portuguese, German, Russian, Japanese, French |
UTC Control | Full OSD Menu access via up-the-cable (Coaxitron® type ) signaling |
DWDR / BLC / HLC | OFF/WDR/BLC/HLC Selectable Adjustable for Level 1~10; also BLC area, HLC color. |
Auto Gain Control | OFF; 2~42dB |
Electronic Shutter | Auto; FLK; or Manual 1/30 (25) to 1/30,000 |
White Balance | Auto / Push Lock / Auto EXT / Manual |
Color Correction | Gamma 0.45~.65, adjustable |
Day & Night | True D/N with motorized IR cut filter Optional color-only and B/W only modes under OSD control |
Digital Slow Shutter (DSS) |
DSS low light boost Off/Auto 2X~16X* |
3D-DNR | Off/Low/Mid/High |
Digital Zoom | 1X~8X |
Defog | Off/Low/Mid/High |
Mirror | Off / H-flip, V-flip, HV flip (rotate) |
Motion Detection | Off/On for programmable zone with sensitivity adjust (pixel change detection) |
Privacy Mask | Off/On with full programmability for 8 selectable zones |
Lens Shading Compensation | Off/Low/Mid/High |
DPC (Defective Pixel Correction) | Off/On |
Other OSD Functions | Camera Title with position; Image Sharpness |
Power Source | 12VDC/24VAC |
Power Consumption | 12VDC:240mA / 24VAC:3.4W max. |
Operating Temperature | 14°F~122°F ; -10°C~50°C |
Storage Temperature | -4°F~140°F ; -20°C~60°C |
Humidity | Less than 80% non-condensing |
Dimensions | 2.28” x 2.28” x 4.77” / 58mm x 58mm x 121.4mm (includes BNC at rear) |
Weight | 0.485 lb / 220g |
Certifications | CE / FCC |
Warranty | 3 years |
