LTS proudly introduces HD-TVI technology, a breakthrough on analog solution helping analog users to maximize their expansion needs.
No more fuzzy pictures from analog systems - LTS HD-TVI systems guarantee long distance real-time HD transmission at 720P/1080P up to 1500ft via coaxial cable; as well as UTP cable with video baluns. It is easy to upgrade an existing analog system to HD without replacing wiring—a huge saving on total cost of ownership.
Main Features:
• Real-time HD Analog Solution at 1080P/720P
HD-TVI solution offers high definition video output at 1080P/720P with frame rate of up-to 30fps; quadruple the clarity of your traditional analog system.
• Universal HD-TVI Technology Ensures Seamless Compatibility
The universal HD-TVI technology provides seamless interoperability with any HD-TVI devices of any brand on the market; making 3rd party device integration a breeze.
• Up to 1500ft Long Distance HD Transmission via Coaxial Cable
HD-TVI guarantees long distance HD video transmission up to 1500ft at 1080P/720P using coaxial cable.
FEATURES
| Camera | |
| Image Sensor | 1/3"Sensor |
| Signal System | NTSC / PAL(Euro Version) |
| Effective Pixels | 1280(H)×720(V) |
| Min. Illumination | 0.01 Lux @ (AGC ON),0 Lux with IR |
| Shutter Speed | NTSC: 1/30 ~ 1/50,000 PAL: 1/25 ~ 1/50,000 |
| Lens | 2.8mm |
| Day & Night | ICR |
| Synchronization | Internal synchronization |
| Video Frame Rate | NTSC:720p@30fps/PAL:720p@25fps |
| HD Video Output | 1 Analog HD output |
| S/N Ratio | More than 52dB |
| General | |
| Working Temperature /Humidity |
-40°F - 140°F (-40 °C - 60 °C) |
| Humidity 90% or less (non-condensing) | |
| Power Supply | 12V DC |
| Power Consumption | Max.3.5W |
| Weather Proof Ratings | IP66 |
| IR Range | 65ft(20m) |
| Dimension | 3.5" × 2.3" (89.6 ×59.1 mm) |
| Weight | 0.9lb(400g) |
