Model

PDC5502

 camera

Image sensor

1/2.8″ Sony 322 Exmor CMOS Sensor

Effective  pixel

1080P(1920X1080)

Electronic Shutter

1/25s ~ 1/100000s

 Iris

F1.6~F22

 Day & Night

             ICR

  Min. Illumination

0.01Lux @(F2.0,AGC ON) ,0 Lux with IR

 Audio compression

G.711-U law

Image Settings

AWB, AGC Adjustable

               Exposure Mode

(Auto/Iris Priority/Shutter Priority/Manual)

    Sharpness, Saturation, Brightness & Contrast Adjustable

WDR Range

  Digital WDR

Noise Reduction

2D/3D-DNR

 Image Orientation

  Mirror/Flip

 Privacy Zone

Yes

Motion Detection

 Yes

 Video compression

  Main chip

NVP2440H

 Video Compression

H.264

 Resolution

50HZ:25fps(1280×720)  (1280×960)

60HZ:30fps (1280×720) (1280×960)

Bit rate

32kbps-16Mbps

 Encode Mode

VBR/CBR

 Image Quality

Five levels under VBR; Free adjustment under CBR

Housing

 Lens

5.1-51mm

Iris

 Auto Iris

 Water-proof

IP67

Bracket

 Yes

Dimensions

153mm×93mm×130mm（L×WxH）

Weight(gross)

920g

PTZ

 Optical Zoom

   10X

IR Distance

  80M

 Pan Rotation Range

0〫~250 〫

Tilt Rotation Range

—5〫~55 〫

 Pan Speed

0.5〫~12 〫/s

Tilt Speed

0.5〫~10 〫/s

 Preset Position

256

others

 Power

DC12V

 working Temp

-35℃~60℃, 10%~90% Humidity
